Aluminium Bi-Fold Doors: Supply Only

Visofold 1000

Visofold can be used in domestic applications as either an alternative to sliding doors, or to open up an entire wall as part of a conservatory.

Used commercially in a bar, café or restaurant, Visofold can create a glazed screen that allows in the maximum ingress of light in inclement weather, and will also easily glide to open up an entire wall in warmer weather. Visofold doors offer a choice of opening configurations to suit any application. Choose to fold the sashes internally or externally, place the opening at the side so the sashes all fold one way, at one end, to create a single entrance door for easy access, or in the middle to give the option of a double door.

All Visofold profiles feature a polyamide thermal break that enhances the thermal performance of the profile and improves the overall U-Value. Profiles feature EPDM high quality gaskets and weather brushes to aid weather resistance.

Visofold complies with the requirements of Building Regulations Document L 2010. Security is assured by multi-point lock mechanisms on main opening sashes, and shoot-bolt locking on floating mullions.

Specification

• Attractive, slimline profiles for reduced sightlines
• Fabricated using mitred corners
• Manufactured using Smarts punch tooling
• Single or dual colour, marine quality polyester powder coat as standard
• 1.5 W/m²K U Value
• Frame width: 102.5mm; Frame depth: 70mm
• 2500mm max height; 1200mm max width
• 100kg max sash weight

Visofold 2000

Visofold 2000 is styled for use on retail or commercial applications such as bars, cafes or shops that require the benefit of opening up an entire façade in good weather, and also providing a glazed screen that allows the maximum ingress of light when closed.

They are manufactured by method of a square cut, non-mitred design with square edged profiles which mimic a timber profile appearance

Specification

• Manufactured using Smarts punch tooling
• Single or dual colour, marine quality polyester powder coat as standard
• 1.6 W/m²K U Value
• Frame width: 102.5mm; Frame depth: 70mm
• 2500mm max height; 1000mm max width
• 100kg max sash weight

Visofold 6000

Visofold 6000’s flexibility makes it suitable for both commercial and residential projects where large opening apertures are required, with the system maximising light and space to give unimpeded views.

This highly-versatile, easy-to-operate system is the perfect option for even the largest project, capable of opening up an entire wall, yet presenting a contemporary, elegant glazed façade when closed.

With high-security glazing, robust locking mechanisms (including multi-point locks on the main opening sashes, and shoot-bolts on the floating mullions), an unrivalled colour range and the option of colour-matched accessories, the system can be tailored to meet each project’s specific requirements.

Delivering the perfect combination of strength and performance, Visofold 6000 profiles feature a polyamide thermal break that enhances the system’s thermal performance as well as resistance.

Fully compliant with the requirements of Building Regulations Document L 2010, the doors have the option of either recessed thresholds for unimpeded, easy access, or rebated thresholds that offer improved weather resistance.

Specification

• 1.5 W/m²K U Value
• 2200mm max height; 1000mm max width
• 100kg max sash weight
• 94mm sash sightline
